Description
SIMPLY MORE Get more done for less. Longer run time per charge and fewer lifetime charge cycles means less spend on batteries. Consistent power, traction and torque, with improved controllability and efficiency, deliver excellent all around jobsite performance.
Specifications
Manufacturer
Skyjack
Model
SJ3219 E
Year
2026
Category
Aerial Work Platforms
Subcategory
DC Electric Scissors
Work Height
24’ 6” (7.47 m)
Raised Platform Height
18’ 6” (5.64 m)
Lowered Platform Height
41” (1.04 m)
Overall Width
32” (0.81 m)
Overall Length
71” (1.80 m)
Stowed Height (Rails Up)
84” (2.13 m)
Stowed Height (Rails Down)
79.6” (2.01 m)
Platform Width (Inside Dimension)
26” (0.66 m)
Platform Length (Inside Dimension)
61” (1.55 m)
Extension Deck (Roll Out)
3’ (0.91 m)
Wheelbase
54” (1.37 m)
Turning Radius (Outside)
65” (1.65 m)
Maximum Drive Height
Full Height
Tire Size
12 x 4 x 8
Ground Clearance
0.5” (1.3 cm)
Ground Clearance (raised)
3.5” (8.9 cm)
Weight
3,236 lbs (1,468 kg)
Gradeability
25%
Lift Time (With Rated Load)
22 sec
Lower Time (With Rated Load)
25 sec
Capacity (Overall)
500 lbs (227 kg)
Distributed Capacity (Main Platform)
250 lbs (113 kg)
Distributed Capacity (Extension Deck)
250 lbs (113 kg)
Local Floor Load (With Rated Load)
168 psi (1,159 kPa)
Overall Floor Load (With Rated Load)
242 psf (11.6 kPa)
Maximum # of Persons
2
Wind Rating
1 @ 28 mph (12.5 m/s)
Tire Type
Solid, N/M
Drive Speed (Stowed)
2.1 mph (3.4 km/h)
Drive Speed (Raised)
0.6 mph (0.9 km/h)
