Description
Simply more Get more done for less. Longer run time per charge and fewer lifetime charge cycles means less spend on batteries. Consistent power, traction and torque, with improved controllability and efficiency, deliver excellent all around jobsite performance.
Specifications
Manufacturer
Skyjack
Model
SJ3215 E
Year
2026
Category
Aerial Work Platforms
Subcategory
DC Electric Scissors
Work Height
20’ 7” (6.27 m)
Raised Platform Height
14’ 7” (4.44 m)
Lowered Platform Height
36” (0.91 m)
Overall Width
32” (0.81 m)
Overall Length
71” (1.80 m)
Stowed Height (Rails Up)
79.5” (2.03 m)
Stowed Height (Rails Down)
66” (1.67 m)
Platform Width (Inside Dimension)
26” (0.66 m)
Platform Length (Inside Dimension)
61” (1.55 m)
Extension Deck (Roll Out)
3’ (0.91 m)
Ground Clearance
0.5” (1.3 cm)
Ground Clearance (raised)
3.5” (8.9 cm)
Wheelbase
54” (1.37 m)
Turning Radius (Outside)
65” (1.65 m)
Tire Size
12 x 4 x 8
Weight
2515 lbs (1141 kg)
Gradeability
25%
Lift Time (With Rated Load)
21 sec
Lower Time (With Rated Load)
28 sec
Drive Speed (Raised)
0.6 mph (0.9 km/h)
Maximum Drive Height
Full Height
Capacity (Overall)
600 lbs (272 kg)
Distributed Capacity (Main Platform)
350 lbs (159 kg)
Distributed Capacity (Extension Deck)
250 lbs (113 kg)
Local Floor Load (With Rated Load)
159 psi (1093 kPa)
Overall Floor Load (With Rated Load)
202 psf (9.7 kPa)
Maximum # of Persons
2
Wind Rating
1 @ 28 mph (12.5 m/s)
Tire Type
Solid, N/M
Drive Speed (Stowed)
2.1 mph (3.4 km/h)
