Description
Skyjack SJ9233 RT
Specifications
Manufacturer
Skyjack
Model
SJ9233 RT
Year
2026
Category
Aerial Work Platforms
Subcategory
Rough Terrain Scissors
Work Height
39’ (11.89 m)
Raised Platform Height
33’ (10.06 m)
Lowered Platform Height
67” (1.70 m)
Overall Width
92” (2.34 m)
Overall Length
176” (4.47 m)
Stowed Height (Rails Up)
110.5” (2.81 m)
Stowed Height (Rails Down)
75” (1.91 m)
Platform Width (Inside Dimension)
74” (1.88 m)
Platform Length (Inside Dimension)
171” (4.34 m)
Extension Deck
5’ (1.52 m)
Ground Clearance
10” (25 cm)
Wheelbase
118” (3.00 m)
Weight
12,500 lbs (5,670 kg)
Gradeability
40%
Turning Radius (Inside)
131” (3.33 m)
Lift Time (With Rated Load)
35 sec
Lower Time (With Rated Load)
30 sec
Drive Speed (Stowed)
3 mph (4.8 km/h)
Drive Speed (Raised)
0.6 mph (1 km/h)
Maximum Drive Height
Full Height
Capacity (Overall)
2,750 lbs (1,247 kg)
Maximum of Persons
7
Tire Type
Solid
Tire Size
31 x 10-20
Diesel Engine
Kubota 24.8 HP D1305
