Description
Skyjack ZB2044
Specifications
Manufacturer
Skyjack
Model
ZB2044
Year
2026
Category
Aerial Work Platforms
Subcategory
Telehandlers
Turning Radius (Outside)
18’ 4” (5.59 m)
Wheelbase
11’ 6” (3.51 m)
Frame Leveling (degrees)
+/- 8
HP @ rpm
168hp @ 2300 rpm
Overall Height - Stowed
9’ (2.74 m)
Overall Width
8’ 6” (2.59 m)
Rated Lift Capacity @ Maximum Reach
7,000 lbs (3,175 kg)
Axles
Axletech steerable outboard planetary
Engine
Cummins Tier 4 Final QSB 4.5C Turbocharged Diesel
Maximum Lift Capacity
20,000 lbs (9,072 kg)
Service Brakes
4 wheel dry disc
Transmission
Dana powershift, 3 speeds forward and reverse
Maximum Lift Height
44’ 10” (13.67 m)
O/A Length - LessForks
20' 3" (6.7m)
Operating Weight
45,000 lbs (20,412 kg)
Steering
3 mode (2 wheel, 4 wheel, crab)
Tires
17.5 x 25 16PR grip lug
Ground Clearance
18” (46 cm)
Max Travel Speed - Forward
20.5 mph (33 kph)
Maximum Forward Reach
27’ 5” (8.36 m)
Parking Brakes
Pinion mounted dry disc on front axle
Rated Lift Capacity @ Maximum Height
12,000 lbs (4,536 kg)
