Description
Simply Transformed Skyjack’S Next Generation Vertical Mast Lifts Provide A Quiet And Versatile Package With Zero Emissions And Other Eco Benefits. Variable Speed Direct Ac Electric Drive Provides Exceptional Duty Cycles, While Their Proportional Drive And Lift Controls Offer Superior Drive Efficiency And Consistent Torque. Eco Rental Companies And Major Contractors Face Increasing Demands For Sustainability Information. Skyjack Has Introduced Its Eco Mark To Support Our Customers By Providing Products That Deliver Benefits In Environmental Performance And Long-Term Sustainability.
Specifications
Manufacturer
Skyjack
Model
SJ20 E
Year
2026
Category
Aerial Work Platforms
Subcategory
Vertical Mast Lifts
Work Height
25’ 6” (7.77 m)
Raised Platform Height
19’ 6” (5.94 m)
Lowered Platform Height
30” (0.76 m)
Overall Width
31.5” (0.80 m)
Overall Length
54” (1.37 m)
Stowed Height
79.5” (2.0 m)
Platform Width (Inside Dimension)
27” (0.69 m)
Platform Length (Inside Dimension)
36” (0.91 m)
Extension Deck (Roll Out)
16” (0.41 m)
Ground Clearance (Stowed)
1” (2.54 cm)
Ground Clearance (raised)
3.5” (9 cm)
Wheelbase
44” (1.12 m)
Turning Radius (Outside)
55” (1.40 m)
Weight
2,440 lbs (1,107 kg)
Gradeability
25%
Lift Time (With Rated Load)
26 sec
Lower Time (With Rated Load)
26 sec
Drive Speed (Stowed)
2 mph (3.0 km/h)
Drive Speed (Raised)
0.3 mph (0.5 km/h)
Maximum Drive Height
Full Height
Capacity
350 lbs (159 kg)
Capacity (Overall)
350 lbs (159 kg)
Local Floor Load (With Rated Load)
148 psi (1,021 kPa)
Overall Floor Load (With Rated Load)
237 psf (11.3 kPa)
Maximum # of Persons
1
Wind Rating
0 (Optional 1 @ 28 mph (12.5 m/s)
Tire Type
Solid, N/M
Tire Size
10” x 4” (252 mm x 102 mm)
