Description
Simply More Skyjack’s new electric scissor lifts are designed with an AC drive system that gives you more: more runtime per charge, more profit from lower maintenance costs, more resale value, and more return on investment.
Specifications
Manufacturer
Skyjack
Model
SJ5545 E
Year
2026
Category
Aerial Work Platforms
Subcategory
DC Electric Scissors
Work Height
51' (15.54 m)
Platform Height
45' (13.72 m)
Lowered Platform Height
65" (1.65 m)
Overall Width
55" (1.4 m)
Overall Length
115" (2.92 m)
Stowed Height (Rails Up)
109.8" (2.79 m)
Stowed Height (Rails Down)
79.5" (2.02 m)
Platform Width (Inside Dimension)
46.8" (1.19 m)
Platform Length (Inside Dimension)
104" (2.64 m)
Extension Deck (Roll Out)
3' (0.91 m)
Ground Clearance (raised)
6" (15 cm)
Wheelbase
92" (2.34 m)
Turning Radius (Inside)
19" (0.48 m)
Turning Radius (Outside)
122" (3.1 m)
Tire Size
16 x 5 x 12
Weight
7,675 lbs (3,481 kg)
Lift Time (With Rated Load)
99 sec
Lower Time (With Rated Load)
55 sec
Drive Speed (Stowed)
2 mph (3.2 km/h)
Drive Speed (Raised)
0.4 mph (0.58 km/h)
Maximum Drive Height
Full Height
Capacity (Overall)
770 lbs (350 kg)
Gradeability
25%
Distributed Capacity (Main Platform)
470 lbs (215 kg)
Distributed Capacity (Extension Deck)
300 lbs (135 kg)
Local Floor Load (With Rated Load)
235 psi (1,622 kPa)
Overall Floor Load (With Rated Load)
242 psf (11.6 kPa)
Maximum # of Persons
3
Wind Rating
2 Up to 22’ (6.7 m) @ 28 mph (12.5 m/s)
Tire Type
Solid, N/M
