Description
The LPT40 Direct Store Delivery (DSD) configuration is an industry-exclusive solution aimed at changing the store delivery process forever.
Specifications
Manufacturer
Big Joe
Model
LPT40 DSD
Year
2026
Category
Pallet Jack
Subcategory
Lithium-Ion Pallet Trucks
Drive
Electric
Operator type
Pedestrian
Load capacity
4000 Ib
Service weight
507 lb
Axle loading, laden (front / rear)
1447 / 2999 lb
Axle loading, unladen (front / rear)
353 / 15 lb
Tire type
Polyurethane
Max gradeability, laden/unladen
6 / 16 %
Service brake
Electromagnetic
Drive motor rating S2 60min
0.9 kW
Lift motor rating at S3 15%
0.8 kW
Battery voltage / nominal capacity
48 / 30 V/Ah
Steering system
Mechanical
Charger output current
15 A
Wheels, number (front/rear) x=drive wheels
1x / 2
Load center distance
24 in
Load distance, center of drive axle to fork X
32.4 in
Wheelbase y
43.5 in
Tire size front
8, 3 * 2.8
Tire size, rear
2, 9 * 3 ,5
"tireSizeRear": { "label": "Additional wheels (caster wheels)", "desc": "2, 9 * 3 ,5"},
2, 9 * 3 ,5
Tread width, rear b11
13.8 in
Lift stroke h3
4.5 in
Height of tiller handle in drive position MIN / MAX h14
25.6 / 46.1 in
Lowered height h13
3.3 in
Overall length l1
58.3 in
Length to face of forks l2
15.7 in
Overall width b1/b2
24 in
Fork dimensions s x e x l
1.97 x 6.22 x 41.33 in
Fork spread bs
20 in
Ground clearance, center of wheelbase m2
0.7 in
Turning radius Wa
51.4 in
Travel speed, laden/unladen
3.1 / 3.4 mph
Lifting speed, laden/unladen
3.9 / 4.9 fpm
Lowering speed, laden/unladen
12.8 / 6.0 fpm
